Air Washer
Energy-Efficient Industrial Cooling & Air Purification Systems
Advance Machines & Components Access Industries manufactures high-efficiency Air Washers designed to deliver clean, cooled, and filtered air to large industrial facilities. By combining evaporative cooling with multi-stage air washing, our systems effectively reduce indoor ambient temperatures while scrubbing dust, particulate matter, and contaminants from the incoming air stream
AIR WASHER – PRODUCT RANGE
| Air Washer Type | Capacity Range | Configuration | Typical Application |
|---|---|---|---|
| 1 Stage Air Washer | 5,000 – 25,000 CFM | Single Stage Cooling & Filtration | Small & Medium Industrial Areas |
| 1 Stage Air Washer | 25,001 – 50,000 CFM | Single Stage Cooling & Filtration | Factories, Workshops & Commercial Areas |
| 2 Stage Air Washer | 50,001 – 75,000 CFM | Two Stage Cooling & Filtration | Large Industrial Applications |
| 2 Stage Air Washer | 75,001 – 1,00,000 CFM | Two Stage Cooling & Filtration | Large Factories, Warehouses & High-Capacity Projects |
Technical Product Classification
| Parameter | 1 Stage – Range 1 | 1 Stage – Range 2 | 2 Stage – Range 3 | 2 Stage – Range 4 |
|---|---|---|---|---|
| Airflow Capacity | 5,000–25,000 CFM | 25,001–50,000 CFM | 50,001–75,000 CFM | 75,001–1,00,000 CFM |
| Air Washer Type | 1 Stage | 1 Stage | 2 Stage | 2 Stage |
| Cooling Method | Evaporative | Evaporative | Two-Stage Evaporative | Two-Stage Evaporative |
| Airflow | Fresh Air | Fresh Air | Fresh Air | Fresh Air |
| Filter / Cooling Media | Available | Available | Pre-Cooling + Cooling Media | Pre-Cooling + Cooling Media |
| Fan Type | Centrifugal / Plug Fan | Centrifugal / Plug Fan | Centrifugal / Plug Fan | Centrifugal / Plug Fan |
| Fan Drive | Belt / Direct Drive | Belt / Direct Drive | Belt / Direct Drive | Belt / Direct Drive |
| Motor | IE3 / IE4 | IE3 / IE4 | IE3 / IE4 | IE3 / IE4 |
| Casing | Double Skin | Double Skin | Double Skin | Double Skin |
| Insulation | PUF / Rockwool | PUF / Rockwool | PUF / Rockwool | PUF / Rockwool |
| Water Circulation | Pump & Distribution System | Pump & Distribution System | Dual Pump & Distribution System | Dual Pump & Distribution System |
| Drain Pan | SS / GI | SS / GI | SS / GI | SS / GI |
| Control | DOL / VFD | DOL / VFD | DOL / VFD | DOL / VFD |
| Application | Industrial / Commercial | Industrial / Commercial | Large Industrial | Large Industrial |
1 STAGE AIRWASHER
AMCAI 1 Stage Airwasher provides effective ventilation, cooling and air filtration for industrial, commercial and agricultural applications. It brings fresh air inside, washes out dust and odor, and delivers cool & clean air.
Features
- High Air Delivery: Wide range from 5,000 to 100,000 CFM
- Efficient Cooling: Evaporative cooling with high efficiency pads
- Dust & Odor Removal: Improves indoor air quality
- Durable Construction: Corrosion resistant body for long life
- Low Maintenance: Easy access for cleaning and servicing
- Energy Efficient: Low power consumption, eco-friendly
TECHNICAL SPECIFICATIONS
| Parameter | Specification |
|---|---|
| Type | 1 Stage Airwasher |
| Airflow Range | 5,000 – 50000 CFM |
| Cooling Efficiency | 70% – 85% |
| Stages | 1 Stage (Cooling + Filtration) |
| Cooling Media | High Efficiency Honeycomb Pads |
| Fan Type | Centrifugal Fan (Direct Drive / Belt Drive) |
| Fan Material | GI / Stainless Steel |
| Body Material | GI Powder Coated / SS 304 |
| Water Pump | Heavy Duty Submersible Pump |
| Water Distribution | Uniform Water Distribution System |
| Control | Manual / Auto (Optional) |
| Voltage | 380V / 415V, 3 Phase, 50Hz |
| Application | Factories, Warehouses, Workshops, Commercial Buildings, Greenhouses |
TECHNICAL DATA
| MODEL | AIRFLOW (CFM) | MOTOR (HP) | FAN TYPE | COOLING PAD SIZE (L x H x W) mm | WATER PUMP (HP) | APPROX. WEIGHT (KG) |
|---|---|---|---|---|---|---|
| AIAWR-5K | 5,000 | 1 | Centrifugal | 600 x 600 x 100 | 0.5 | 90 |
| AIAWR-10K | 10,000 | 2 | Centrifugal | 900 x 600 x 100 | 0.5 | 150 |
| AIAWR-15K | 15,000 | 3 | Centrifugal | 900 x 900 x 100 | 0.5 | 210 |
| AIAWR-20K | 20,000 | 5 | Centrifugal | 1200 x 900 x 100 | 0.75 | 270 |
| AIAWR-30K | 30,000 | 7.5 | Centrifugal | 1500 x 1200 x 100 | 1 | 360 |
| AIAWR-50K | 50,000 | 15 | Centrifugal | 1800 x 1500 x 150 | 1.5 | 520 |
2 STAGE AIRWASHER
AMCAI 2 Stage Airwasher is designed for maximum cooling and superior air filtration. It is ideal for harsh climate conditions and areas where higher cooling efficiency and cleaner air are required.
Features
- High Air Delivery: Wide range from 5,000 to 100,000 CFM
- Efficient Cooling: Evaporative cooling with high efficiency pads
- Dust & Odor Removal: Improves indoor air quality
- Durable Construction: Corrosion resistant body for long life
- Low Maintenance: Easy access for cleaning and servicing
- Energy Efficient: Low power consumption, eco-friendly
TECHNICAL SPECIFICATIONS
| Parameter | Specification |
|---|---|
| Type | 2 Stage Airwasher |
| Airflow Range | 5,0001 – 100,000 CFM |
| Cooling Efficiency | 85% – 95% |
| Stages | 2 Stage (Pre Cooling + Main Cooling) |
| Cooling Media | High Efficiency Honeycomb Pads (Dual) |
| Fan Type | Centrifugal Fan (Direct Drive / Belt Drive) |
| Fan Material | GI / Stainless Steel |
| Body Material | GI Powder Coated / SS 304 |
| Water Pump | Heavy Duty Submersible Pump |
| Water Distribution | Uniform Water Distribution System |
| Control | Manual / Auto (Optional) |
| Voltage | 380V / 415V, 3 Phase, 50Hz |
| Application | Industries, Textile Mills, Greenhouses, Warehouses, Commercial Buildings |
TECHNICAL DATA
| MODEL | AIRFLOW (CFM) | MOTOR (HP) | FAN TYPE | COOLING PAD SIZE (L x H x W) mm | WATER PUMP (HP) | APPROX. WEIGHT (KG) |
|---|---|---|---|---|---|---|
| AIAWR2-75K | 75,000 | 20 | Centrifugal | 2000 x 1800 x 150 (2 Stage) | 2 | 850 |
| AIAWR2-100K | 100,000 | 25 | Centrifugal | 2400 x 1800 x 150 (2 Stage) | 2 | 1100 |
Why Choose Us
Engineering Expertise
Tailored industrial HVAC, cooling, and ventilation solutions backed by over 13 years of core industry experience.
Application-Specific Design
Every system is customized based on your facility’s layout, heat load, airflow dynamics, and operating conditions.
Energy-Conscious Approach
Engineered to maximize airflow and performance while reducing operational electricity costs.
Quality & Reliability
Built with heavy-duty components designed for continuous, long-term operation in harsh industrial environments.
Turnkey Execution
Complete end-to-end support—from initial site audit and technical design to supply, installation, commissioning, and after-sales service.
